See it in Action

2018 Key Improvements

New and Improved Battery:

We upgraded the 2018 batteries to 14Ah and we're using the new Samsung 35E cells, which are super energy-dense and reliable.

*The 2018 battery is not compatible with 2016/2017 models. We may be offering the 2016/2017 style battery with the upgraded 14Ah cells in the future.

Front Suspension Fork:

Our custom RadMini suspension fork has 60 mm of travel, preload adjustment, and lockout. Combined with the fat tires, you're in for one smooth ride. (This feature replaces the front rack found on previous models.)

Front / Rear Rack Mounts:

Our 2018 lineup has a brand new line of universal racks and baskets that are compatible across all 2018 models. The 2018 RadMini no longer comes stock with a front rack.

New Color Scheme:

The classic black and white have been improved with fresh styling and accents.

Description

The RadMini is the first and only electric folding fat bike with heavy duty front (optional) and rear cargo racks and a powerful 750W, 48V power system. Equipped with comfortable but compact 20" x 4" tires, the RadMini can be conveniently folded in order to store and transport the bike more easily. The RadMini has the ability to take on many tasks you would not expect from a folding bike such as hauls from the grocery store, challenging terrain, and rough roads all without breaking a sweat.

Available Colors:

Black (black grips & seat)
White (brown grips & seat)

Product Overview

Powerful 750W Bafang geared hub motor
48V 14Ah (672Wh) Lithium-Ion battery using Samsung cells
- Rated for 800 charge cycles
Total Payload Capacity: 275 lbs
- Rear Rack: 40 lbs
20 mph top speed
Estimated 25-45+ mile range
Half twist throttle and intelligent 5 level pedal assist
Full LCD display including speedometer, wattmeter, and odometer
Integrated headlight
Front suspension fork with preload adjustment and lockout
7-speed Shimano Tourney drivetrain
180 mm Tektro mechanical disk brakes
20" x 4" Kenda Krusade Sport tires
Bike Weight: 63.7 lbs

Accessories

Click here to view all available accessories for the RadMini.

Shipping

Shipping is free to the lower 48 states! How long do bikes take to arrive once shipped? Click on the "Shipping" tab to view our handy shipping map!

FAQ's

For answers to frequently asked questions, check out our Help Center .

Sizing

The RadMini electric folding fat bike comes in one frame size with recommended rider heights of 5'2" - 6'2" (28" stand over height)

What Comes with the Bike

Battery charger
Toolkit
Owner's manual

The RadMini has the ability to take on many tasks you would not expect from a folding bike. When space is limited but you need a workhorse, the RadMini is your go-to choice!

The RadMini has the ability to take on many tasks you would not expect from a folding bike. When space is limited but you need a workhorse, the RadMini is your go-to choice!

Key Features

Key Features

Each component of the RadMini was hand selected by our team of experienced ebike enthusiasts who understand the expectations and real world applications ebikers are looking for. The end result blends our favorite features of on and off road ebiking. We're proud to ride this fully featured folding fat bike that is robust and powerful.

Each component of the RadMini was hand selected by our team of experienced ebike enthusiasts who understand the expectations and real world applications businesses are looking for. The end result blends our favorite features of on and off road ebiking. We're proud to ride this fully featured folding fat bike that is robust and powerful.

750W Geared Hub Motor

The Bafang geared hub motor gives you 80Nm of torque to get you to a top speed of 20 mph with ease. Conquer hills and power through loose terrain like never before.

14Ah Lithium-Ion Battery

Our new and improved 48V 14Ah (672Wh) batteries give you an estimated 25-45 miles per charge while maintaining a sleek profile.

Twist Grip Throttle

Get 750W of power on-demand with the twist grip throttle. The included on/off button helps prevent accidental activation and allows you to only use the throttle when you want to.

Front Suspension Fork

Our custom RadMini suspension fork has 60mm of travel, preload adjustment, and lockout. Combined with the fat tires, you're in for one smooth ride.

750W Geared Hub Motor

The Bafang geared hub motor gives you 80Nm of torque to get you to a top speed of 20 mph with ease. Conquer hills and power through loose terrain like never before.

14Ah Lithium-Ion Battery

Our new and improved 48V 14Ah (672Wh) batteries give you an estimated 25-45 miles per charge while maintaining a sleek profile.

Twist Grip Throttle

Get 750W of power on-demand with the twist grip throttle. The included on/off button helps prevent accidental activation and allows you to only use the throttle when you want to.

Front Suspension Fork

Our custom RadMini suspension fork has 60mm of travel, preload adjustment, and lockout. Combined with the fat tires, you're in for one smooth ride.

Folding Frame Design

There when you need it. Gone when you don't.

Reduce your footprint without sacrificing power. The RadMini can quickly and easily be folded to make transporting and storing the bike a breeze.

With two folding points (one on the handlebar stem and one in the middle of the frame), you can turn your rugged, all-terrain powerhouse into a discrete, convenient mode of transporation.

Folded Length

44"

Folded Width

24"

Folded Height

29"

Folding Frame Design

There when you need it. Gone when you don't.

Reduce your footprint without sacrificing power. The RadMini can quickly and easily be folded to make transporting and storing the bike a breeze.

With two folding points (one on the handlebar stem and one in the middle of the frame), you can turn your rugged, all-terrain powerhouse into a discrete, convenient mode of transporation.

Folded Length

44"

Folded Width

24"

Folded Height

29"

New Universal Racks

Universal racks that are compatible across all of our 2018 electric bikes are available now!

New Universal Racks

Universal racks that are compatible across all of our 2018 electric bikes are available now!

Performance

Performance

Spend less time charging and more time riding.

Our specialty is battery and electric motor technology and we understand you want to commute to and from work, climb hills, stand-your-own in traffic and get to your destination faster. We have what you want and it's 48V and 750W of clean power. The RadMini gets an estimated range of 25-45+ miles per charge allowing you to get a full day's worth of use without having to stop to plug in.

48V and 750W of power results in an electric fat bike capable of tackling terrain and going the distance unlike the lower power and voltage options on the market.

Unlike other electric bikes with low capacity 36V batteries, we splurged on our battery packs because we know that this is the single most important component of any electric bike. The 48V 14Ah battery packs a punch and has the capacity and range to be there for you when you need it most at the end of a long ride. At only 7.7 lbs, this is one of the lightest and most energy dense battery packs ever supplied on an electric bike. Combine that with the external battery meter and easy removal for charging and transport, you have a feature rich battery pack you can depend on.

Estimated Range

25-45+ Miles per Charge

Charge Time

5-6 Hours

Top Speed

20 mph

Brushless Geared Hub Motor

A hub motor is an electric motor incorporated into the hub of the wheel. These motors are compact, maintenance free, and discreet. Hub motors are the most common drive method for ebikes today and offer a number of advantages.

We applied our experience with years of taking ebike motors to their limits in high-performance applications and have outfitted the RadMini with a powerful, lightweight, brushless geared hub motor specifically designed for use with our 15 amp continuous motor controller and 48V battery pack.

Key Points:

The motor is mounted in the rear wheel which increases traction when starting on hills and provides greater stability compared to front hub motors.
An internal planetary gear provides ample starting torque and a high top speed while keeping the weight of the bike low for floating over snow and sand. Geared hub motors have internal gears which allow the high speed and high-efficiency motor inside to match the speed of the 20'' wheels.
Geared hub motors typically weigh around 50% less than a direct drive hub motor with similar performance.
The motor also includes an internal freewheel which means when the motor is off the resistance is greatly reduced and it feels more like pedaling a regular bike.
The compact hub motor is so small most people will not even know it’s there until you fly by them on a hill!

Spend less time charging and more time riding.

Our specialty is battery and electric motor technology and we understand you want to commute to and from work, climb hills, stand-your-own in traffic and get to your destination faster. We have what you want and it's 48V and 750W of clean power. The RadMini gets an estimated range of 25-45+ miles per charge allowing you to get a full day's worth of use without having to stop to plug in.

48V and 750W of power results in an electric fat bike capable of tackling terrain and going the distance unlike the lower power and voltage options on the market.

Unlike other electric bikes with low capacity 36V batteries, we splurged on our battery packs because we know that this is the single most important component of any electric bike. The 48V 14Ah battery packs a punch and has the capacity and range to be there for you when you need it most at the end of a long ride. At only 7.7 lbs, this is one of the lightest and most energy dense battery packs ever supplied on an electric bike. Combine that with the external battery meter and easy removal for charging and transport, you have a feature rich battery pack you can depend on.

Estimated Range

25-45+ Miles per Charge

Charge Time

5-6 Hours

Top Speed

20 mph

Brushless Geared Hub Motor

A hub motor is an electric motor incorporated into the hub of the wheel. These motors are compact, maintenance free, and discreet. Hub motors are the most common drive method for ebikes today and offer a number of advantages.

We applied our experience with years of taking ebike motors to their limits in high-performance applications and have outfitted the RadMini with a powerful, lightweight, brushless geared hub motor specifically designed for use with our 15 amp continuous motor controller and 48V battery pack.

Key Points:

The motor is mounted in the rear wheel which increases traction when starting on hills and provides greater stability compared to front hub motors.
An internal planetary gear provides ample starting torque and a high top speed while keeping the weight of the bike low for floating over snow and sand. Geared hub motors have internal gears which allow the high speed and high-efficiency motor inside to match the speed of the 20'' wheels.
Geared hub motors typically weigh around 50% less than a direct drive hub motor with similar performance.
The motor also includes an internal freewheel which means when the motor is off the resistance is greatly reduced and it feels more like pedaling a regular bike.
The compact hub motor is so small most people will not even know it’s there until you fly by them on a hill!

Safety

Safety

LED Headlight

Turn on the integrated, high-powered LED headlight with the press of a button to light the path ahead on your next adventure. Never get left in the dark.

Powerful Brakes

Front and rear 180mm Tektro mechanical disk brakes provide you with strong stopping power, even in loose terrain. Stop faster when it counts the most.

Motor Safety Cutoff

Both brake levers automatically cut off the motor power when they are applied to keep you safe in even the most surprising situations.

Locking Hinges

Ride the RadMini with confidence knowing the hinges are locking and include safety redundencies to keep the frame solid and sturdy.

LED Headlight

Turn on the integrated, high-powered LED headlight with the press of a button to light the path ahead on your next adventure. Never get left in the dark.

Powerful Brakes

Front and rear 180mm Tektro mechanical disk brakes provide you with strong stopping power, even in loose terrain. Stop faster when it counts the most.

Motor Safety Cutoff

Both brake levers automatically cut off the motor power when they are applied to keep you safe in even the most surprising situations.

Locking Hinges

Ride the RadMini with confidence knowing the hinges are locking and include safety redundencies to keep the frame solid and sturdy.

Tech

Tech

All the information you need at the tips of your fingers.

The Rad Power Bikes LCD display provides you with all the information you need when out on a ride. It's securely mounted directly to the handlebars and the display angle can be adjusted to accommodate different sized riders.

Speedometer

Full speed ahead with the large speed display.

Wattmeter

A handy power meter to show you how much electricity you are using at any given time.

Battery Life

A fuel gauge for your electrons!

Pedal Assist Level

Indicates the pedal assist level. The higher the number the more the motor will boost you when you pedal.

Trip Odometer

See how far you go on your next epic adventure.

Odometer

Calculate how many miles you didn't drive this year and how much money you saved on gas!

USB Charging

Charge your phone or portable electronics on the go with the provided USB port.

All the information you need at the tips of your fingers.

The Rad Power Bikes LCD display provides you with all the information you need when out on a ride. It's securely mounted directly to the handlebars and the display angle can be adjusted to accommodate different sized riders.

Speedometer

Full speed ahead with the large speed display.

Wattmeter

A handy power meter to show you how much electricity you are using at any given time.

Battery Life

A fuel gauge for your electrons!

Pedal Assist Level

Indicates the pedal assist level. The higher the number the more the motor will boost you when you pedal.

Trip Odometer

See how far you go on your next epic adventure.

Odometer

Calculate how many miles you didn't drive this year and how much money you saved on gas!

USB Charging

Charge your phone or portable electronics on the go with the provided USB port.

Components

Components

Rad Power Bikes sources components from the top manufacturers in the bicycle industry, making our ebikes durable, reliable, and easy to maintain. Since the majority of the components we use are commonplace in the bicycle industry, any reputable bike mechanic can service our bikes without issue.

Rad Power Bikes sources components from the top manufacturers in the bicycle industry, making our ebikes durable, reliable, and easy to maintain. Since the majority of the components we use are commonplace in the bicycle industry, any reputable bike mechanic can service our bikes without issue.

Electronics

BATTERY

48V 14Ah (672Wh) with Lithium NCA 18650 Samsung 35E Cells, Rated for 800 Charge Cycles

CHARGER

48V 2 Amp Smart Charger, Operates On Both 110V and 230V AC Power Outlets

CONTROLLER

48V, 750W

DISPLAY

Backlit LCD with Charge Indicator, Speedometer, Odometer, Trip Odometer, Pedal Assist Level, Wattmeter, and More

HUB MOTOR

750W Brushless Bafang Geared Hub Motor with 80Nm of Torque

LIGHTS

Front 300 Lumen LED Headlight And Rear LED Tail Light

PEDAL ASSIST

Intelligent 5 Level Pedal Assist with 12 Magnet Cadence Sensor

THROTTLE

Half Twist Throttle with On/Off Button

WIRING

Water Resistant Connectors and Wiring Harness

USB PORTS

Display: 5V, .5 Amp

Bike Components

BRAKE LEVERS

Aluminum Alloy Comfort Grip Levers with Motor Cutoff Switch

BRAKES

Front and Rear 180 mm Tektro Aries Mechanical Disk Brakes

CASSETTE

7-Speed Shimano Freewheel MF-TZ21, 14-28 Tooth

CHAIN

KMC Z7 Rustbuster

CRANKSET

48 Tooth ProWheel Pioneer Aluminum Alloy Crankset, Dual Chainring Guard

DERAILLEUR

7-Speed Shimano Tourney

FENDERS

Optional

FORK

Custom Rad Power Bikes Suspension Fork with 60 mm of Travel, Preload Adjustment, and Lockout

FRAME

6061 Aluminum Alloy

GRIPS

Durable Imitation Leather Ergonomic Grips

HANDLEBARS

Aluminum Alloy

HEADSET

Semi-Integrated, 1-1/8" Straight Steerer Tube

KICKSTAND

Heavy Duty Aluminum with Wide Plastic Foot

PEDALS

Wellgo Forged Aluminum Folding Pedals with Reflectors

RACKS

Front: Optional

Rear: Included, 40 lbs Carrying Capacity

RIMS

Double Wall 36H

SADDLE

Velo Plush with Lifting Handle

SEATPOST CLAMP

Quick Release

SHIFT LEVER

Shimano SL-TX50-7R Thumb Shifter

SPOKES

12 Gauge Stainless Steel Spokes and Nipples, Black

STEM

Aluminum Alloy, Length: 50mm + 13º (15mm Rise) with 2.9" of Height Adjustment

TIRES

20’’ x 4’’ Kenda Krusade Sport Tires

RadMini Sizing Chart

FRAME SIZE

17" (Unisex Medium)
Recommended Rider Heights: 5'2" - 6'2"

HANDLEBAR HEIGHT

Max: 48.5" / Min: 46"

HANDLEBAR REACH

16"

SEAT HEIGHT

Max: 36" / Min: 27"

*Measured from bottom of pedal stroke

STANDOVER HEIGHT

28"

TOTAL LENGTH

67"

WHEELBASE

43.5"

FOLDED LENGTH

44"

FOLDED WIDTH

24"

FOLDED HEIGHT

29"

FRONT DROPOUT WIDTH

135 mm

REAR DROPOUT WIDTH

150 mm

BOTTOM BRACKET SHELL WIDTH

100 mm
Square Taper Bottom Bracket

SEAT TUBE LENGTH

17.25"

TOP TUBE LENGTH (effective)

23"

HEAD TUBE

4.75"

CHAIN STAY

19"

HANDLEBAR WIDTH

26"

CRANK LENGTH

170 mm

SEATPOST DIAMETER

27.2 mm

MAX FRONT TIRE WIDTH

4"

MAX REAR TIRE WIDTH

4"
